Bambu Lab PLA Glow
Bambu PLA Glow
PLA Glow stands out due to its incorporation of a unique additive: luminous powder. This variant retains the familiar qualities of traditional PLA, including easy printing, high quality, and exceptional overall mechanical properties. What sets PLA Glow apart is its distinctive feature - it glows in the dark. This makes it the optimal selection for crafting luminous nameplates, logos, jewelry, and various models that require a captivating glow effect.
Unique Glow in Low Light Conditions
Bambu PLA Glow incorporates a distinct additive: luminous powder, which imparts a special property to printed objects, causing them to emit a captivating glow in the dark.
Printing Tips
• Drying conditions: 55℃ for 8 hrs. Store in a dry environment after use. Dry before use if the material absorbs moisture. For more details please refer to: Filament drying instructions on WIKI.
• Printing with a 0.2 mm nozzle is not recommended; instead, it is advised to use a 0.4 mm nozzle for optimal results.
• The model's luminous intensity diminishes over time, but exposure to ultraviolet or sunlight for a brief period (approximately 2 hours) can rejuvenate its glow. However, prolonged or frequent irradiation may expedite PLA aging.
• Not suitable for AMS lite: Utilizing AMS lite may result in high feed resistance and an increased risk of feed failure. Consider alternative methods such as pre-use drying for better outcomes.
Product Features
- Unique Glow in Low Light Conditions
- Includes Basic Reusable Spool
- Diameter: 1.75mm +/- 0.03mm
Cautions for Use
- AMS Compatible, but can lead to faster wear on internal components
- AMS lite NOT Compatible
- 0.2 mm Nozzle Not Compatible
- Note: A hardened nozzle is required when printing regularly.
Recommended Printing Settings
| Drying Settings (Blast Drying Oven) | 55 °C, 8 h |
| Printing and Keeping Container's Humidity | < 20% RH (Sealed, with Desiccant) |
| Nozzle Temperature | 190 - 230 °C |
| Bed Temperature (with Glue) | 35 - 45 °C |
| Printing Speed | < 250 mm/s |
Physical Properties
| Density | 1.26 g/cm³ |
| Vicat Softening Temperature | 56 °C |
| Heat Deflection Temperature | 55 °C |
| Melting Temperature | 155 °C |
| Melt Index | 23.3 ± 2.4 g/10 min |
Mechanical Properties
| Tensile Strength | 32 ± 3 MPa |
| Breaking Elongation Rate | 8.6 ± 1.2 % |
| Bending Modulus | 2640 ± 130 MPa |
| Bending Strength | 76 ± 4 MPa |
| Impact Strength | 27.3 ± 2.2 kJ/m² |
